AM/NS Hot Rolled Steel
Symbol Of Reliability
AM/NS Hot Rolled SteelForging A Passion. Building The Nation.
The strength you can rely on.
Our state-of-the-art hot rolling mills have a rated capacity of 7.1 MTPA. The facilities include a conventional hot rolling mill and a modern compact strip mill, which are capable of producing a wide range of hot rolled products in sizes ranging from 1 mm to 25 mm for various applications. The mills are equipped with an advanced automation system for
producing products as per the required dimensions and sizes.
AM/NS Stallion is our branded product for
hot rolled steel for the retail channel.
×
Features
Best-in-class tolerance
Consistency of properties
Guaranteed flatness
Wide range of customised sizes
Applications
Assurity & Reliability. Assurity & Reliability. Assurity & Reliability.
Specifications
Product Application
| From | Upto Not including | < 1200 | 1200 - 1500 | 1500 - 1800 | 1800 - 2000 |
| 1.5 | 2 | ±0.11 | ±0.12 | ±0.14 | ±0.14 |
| 2 | 2.5 | ±0.12 | ±0.14 | ±0.15 | ±0.16 |
| 2.5 | 3 | ±0.13 | ±0.14 | ±0.16 | ±0.17 |
| 3 | 4 | ±0.14 | ±0.16 | ±0.17 | ±0.18 |
| 4 | 5 | ±0.16 | ±0.17 | ±0.18 | ±0.19 |
| 5 | 6 | ±0.17 | ±0.18 | ±0.19 | ±0.20 |
| 6 | 8 | ±0.19 | ±0.20 | ±0.20 | ±0.23 |
| 8 | 10 | ±0.21 | ±0.22 | ±0.22 | ±0.26 |
| 10 | 12.5 | ±0.23 | ±0.24 | ±0.24 | ±0.28 |
| 12.5 | 15 | ±0.24 | ±0.25 | ±0.26 | ±0.30 |
| 15 | 20 | ±0.26 | ±0.28 | ±0.30 | ±0.33 |
| The thickness tolerances depend on specification like ASTM, IS, EN, DIN etc. However, the above table represents the typical thickness tolerances offered. | |||||
| PRODUCT SEGMENT | GRADES | GENERAL APPLICATIONS |
| Cold Forming and Deep Drawing | EN 10111 DD11 to DD14 IS 1079 HR0 to HR4, ISH270C to ISH270E JIS G 3131 SPHC/SPHD/SPHE ASTM A 1011 CS Type B |
Automotive Brackets, Compressor Shells, Tillers |
| Re-rolling Steel | IS 11513 CRO - CR8 SAE1005 to SAE1010 |
Re-rolling |
| MC / HC Steel | SAE J403 - SAE_1012 to 1080 | Precision Tubes for Automotive, Chains, Sprockets etc |
| HSLA Steel | EN 10338_FB450 to FB590 / FB590 HHE IS 5986 ISH590F |
Control Arm, Rear Twist Beams, Trailing Arms |
| Dual Phase Steel | EN 10338_ DP600 IS 5986 ISH590Y |
Steel Wheels Disc |
| Boron Steel | EN 10083_28MnB5, 34MnB5, 20MnB5, 22MNB5, 26MnB5 |
Plough Disc, Stabiliser Bar, Door Impact Beams |
| Line Pipe | API 5L GR B to X-80 (Non Sour Applications) API 5L GR BMS to X-65MS (Sour Applications) |
Line Pipes for Oil & Gas Industry |
| Structural Steel | EN 10025 S235/S275/S355 _ J2/JO/JR IS 2062 E 250 to 350 A/BO/BR/C, E 450 A/BR ASTM A 1011 SS 33/ HSLA GR50 CL1 ASTM A 1018 HSLA GR60 CL1 / SS 33 ASTM A 283 GR C ASTM A 36 ASTM A 570 GR50 ASTM A 572 GR50 TYPE 1/ GR50 TYPE 2 DIN 17100 ST 37.2/44.3/52.3 JIS G 3101 SS400 JIS G 3106 SM 490 A |
Bridges, Wind Towers, Fabrication, PEB |
| Ship Building Grades | ASTM A131 _ A, B, D, E, AH 32, AH 36, DH 32, DH 36 , ABS class, DNV-GL class, IRS class, LR class, NKK class, RINA class |
Ship Fabrication |
| Corrosion Resistant Steel | IRSM 41 EN_10155_S355J2G1W / S355_JOWP ASTM A588 Grade A/Grade B/ Grade K BS 4360 WR 50A JIS G 3125 SPAH |
Railway Coaches & Frames |
| Boilers and Pressure Vessels Grades | ASTM A516 Gr 55/60/70 ASTM A515 Gr 60/70 A285 Gr C ASTM A 285 Grade C ASTM A 573 Grade 70 IS 2041 R220/R260 |
Boilers & Pressure Vessels |
| LPV Grades | EN_10120_P245NB/P265NB IS 6240 JIS 3116 SG255/SG295 |
Gas Cylinders, Refrigerant Cylinders |
| Chequered Plates IS 3502 | ASTM_A_36 DIN_17100_ST 37.2 BS_EN_10025_S275_JR |
Industrial Flooring Foot Over Bridges Heavy Equipment Machinery Platforms |
Get to know more
If you would like to discover our product in detail, simply download the brochure
