Pre-Painted Galvanised Steel
Khushiyon ke Rang, AM/NS ke Sang
Colour Coated Steel
Pre-Painted Galvanised Steel
Pre-Painted Galvanised SteelColour Coated steel with a spectrum of durability and style
AM/NS Colour is our branded product for Galvanised Pre-Painted Steel
To boost the aesthetic value of every house, we present Galvanised Pre-Painted Steel that comes with Anti-Fading technology.
This product is strong, durable, and consistent in its properties for protection, aesthetics, and longevity.
×
Features
Corrosion Resistance
Fire Resistant
Anti Fading
Strength
Sustainability
Applications
Durability and Style. Durability and Style. Durability and Style. Durability and Style.
Specifications
Quality Test
Guidelines
Thickness
0.25 - 1.00 mm
Width
900 - 1450 mm
Coil Id
508/610 mm
Dry Film Thickness
Top (14 to 25) / Back (5 to 10)
Metal Zinc Coating
Min 80 - 275 gsm
Substrate
Hot Dip Galvanised (Zinc Coated)
Hardness
60 - 65 HRB for Soft Grades; Min 85 HRB for Hard Grades
Guard Film - Optional
50 Microns
Profile Sheet
Trapezoidal
| Properties | Standard / Test Method | Results |
| Specular Gloss | EN 13523-2 [2001] | 50 - 60 |
| Pencil Hardness | EN 13523-4 [2001] | H - 2H |
| Resistance to Rapid Deformation (Impact Test) | EN 13523-5 [2014] | 100KG - CM |
| Adhesion after Indentation (Cupping Test) | EN 13523-6 [2002] | > 6.5mm |
| Resistance to Cracking on Bending (T-bend Test) | EN 13523-7 [2014] | > 1T |
| Scratch Resistance | EN 13523-12 [20117] | > 1.5KG |
| Resisitance to Salt Spray (fog) |
EN 13523-8 [20117] IS14246 [2013] Class-1 and Class-2 |
> 600 hrs |
| Resisitance to Fluorescent UV Light and Water Condensation | ASTM D2244 | Moderate |
Get to know more
If you would like to discover our product in detail, simply download the brochure
