Magnelis®

Collaborating with Nature to Combat Corrosion

3x Increased Lifetime Compared to Hot Dip Galvanised Solutions

Magnelis®, produced on a classic hot dip galvanising line, comprises a unique chemical composition of zinc, 3.5% aluminium, and 3% magnesium to provide an unprecedented level of protection against corrosion creep from cut edges, local damage or sub-layer scratches, even in the most hostile environments.

Features

Excellent Corrosion Resistance

Remarkable Self Healing Effect

Environmentally Friendly

Cost Effective

Features

< Prev Next >

Applications

Sustainable Self-healing Sustainable Self-healing Sustainable Self-healing Sustainable Self-healing

Specifications

Range of Coating Weights

Tests and Certifications

TECHNICAL SPECIFICATIONS
Thickness	0.4 - 3.2 mm
Width	750 - 1650 mm
Coating	Upto ZM450
Steel grades:	EN10346 - 2015
	Commercial Quality	DX 51 D
	Forming Quality	DX 52 D - DX56 D
	Structural Quality	S 250 GD - S550 GD
	HSLA Grades	HX340 LAD - HX 500 LAD
	IS 18513-2023
	Commercial Quality	IZMCCR0 - IZMCCR1
	Forming Quality	IZMCCR2
	Structural Quality	IZMC300S - IZMC570S
	HSLA Grades	IZMC310LA - IZMC620LA
Surface type	Skinpassed as per requirement
Surface treatment	Epassivation Chrome free passivation, Easy film*

*On request

RANGE OF COATING WEIGHTS
According to EN 10346:2015
Coating Designation	Minimal total coating mass both surfaces (g/m2)		Theoretical guidance values for coating thickness per surface in the single spot test (μm)
	Triple spot test	Single spot test	Typical value	Range
		Zinc-Magnesium alloy coating masses (ZM)
ZM70	70	60	5.5	4 to 8
ZM90	90	75	7	5to 10
ZM120	120	100	9	6to 14
ZM175	175	145	13	9to 18
ZM200	200	170	15	10 to 20
ZM250	250	215	19	13 to 25
ZM310	310	265	24	18 to 31
ZM430	430	365	35	26 to 46
ZM620*	620	525	50	34 to 66
