Galvanised Steel

Galvanised Steel

Unparalleled Protection that #LastsForLonger

With its exceptional surface finish, corrosion resistance, close-dimensional tolerances, excellent formability and commitment to the environment, Galvanised Steel ensures your projects stand the test of time.

Send Enquiry

Download Brochure

Coated Steel

Galvanised Steel

Unmatched Quality & Durability

For protection, aesthetics, and longevity

When it comes to Galvanised Steel, AM/NS India is the ultimate choice. By choosing our Galvanised Steel, you are not only opting for a high-performance material but also supporting eco-friendly practices. You can have confidence that your construction and manufacturing endeavours will stand the test of time, both in terms of durability and environmental responsibility.

Features

Excellent surface finish

Corrosion Resistance

Close-dimensional tolerances

Excellent formability

Environment Friendly

BIS-approved

Features

< Prev Next >

Applications

Unparalleled Protection. Unparalleled Protection. Unparalleled Protection. Unparalleled Protection.

Specifications

Thickness & Tolerance

Thickness	0.25-3.00 mm
Thickness (0.25 - 0.60 mm)	900 to 1250 mm
Thickness (0.61 - 1.80 mm)	900 to 1250 mm*
Thickness (1.81- 2.2 mm)	900 to 1500 mm
Thickness (2.21- 3.20 mm)	900 to 1250 mm
Coil ID	508/610 +/- 20mm
Coil Weight	25 MT Max
Grades	IS 277 2018 GP
Coating Type	Hot Dip Galvanised
Coating Mass	80 to 275 gsm**
Spangles	Regular / Mini Spangles
Post Treatment	Trivalent Chromated and Dry / Oiled Hexavalent Chromated and Dry / Oiled
Hardness	Max 65 HRB max
Chemical Composition	% C_MAX - 0.1000 % % MN_MAX - 0.500 % % S_MAX - 0.0350 % % P_MAX - 0.0300% % Al_ MIN - 0.0200%

Note: *can be supplied up to 1400 mm in 0.6 mm- 1.8 mm
**can be extended up to 450 gsm.

Range	Nominal Tolerance (micron)
<= 0.30	+/-20
0.31 to 0.40	+/-25
0.41 to 1.00	0.41 - 0.6 mm: +/-30 0.61 - 1.0 mm: +/-40
1.01 to 1.50	+/-50
1.51 to 2.00	+/-60
2.01 to 2.50	+/-80
2.51 to 3.00	+/-100
